Chevrolet C8A HUW reference thread

[Alex van de Wetering]

last part for now

[Alex van de Wetering]

Well, one more...

By the way, does anyone have one of tose Chorse horse filter assemblies and one exhaust tube lying around? My Chore Horse came without them.

Alex

[cmperry4]

Some great detail shots here - nothing I have would add to what Rob and Alex have posted. I am also going to have to make up a map table at some future date.

[Bruce Parker (RIP)]

The pics showing the battery hold down posts with wing nuts under the wireless table is interesting. Can anyone come up with dimensions for these so I can make up a set for my HUW? All I have left on the floor is four tabs welded to the floor.

Bruce

[Ian McCallum]

Originally Posted by Bruce Parker

The pics showing the battery hold down posts with wing nuts under the wireless table is interesting. Can anyone come up with dimensions for these so I can make up a set for my HUW? All I have left on the floor is four tabs welded to the floor.

Bruce

Bruce, a fellow enthusiast over here is currently restoring an HUA which was very complete internally although suffered from years of British weather exposure on the external skins! However the two battery frames and four lead battery trays are all present and I am sure I can source some dimensions. Unfortunately the previous owner had stripped out the interior and although most large lumps are obviously identifiable as to where they should go some decent drawings/photos would certainly assist with the reinstatement detail/wiring runs. Likewise any 'stowage diagrams/information' greatly appreciated.
Ian :
