How To: New Wire-5 project (Bergeron)

[Robert Bergeron]

I treated the plywood on both sides with a water repellent sealer / stain . I have seen the plywood come apart because of water seeping in by the numerous screw and bolt holes in the roof in these old boxes . I also primed all the exposed metal before putting in the finishing plywood for the ceiling . Lesson learned from my first restoration.

[Phil Waterman]

Hi Robert

What are using to cover the roof? I believe it was painted canvas, I found a substitute when I restored the S56 shelter on my C60S. It was commercial grade reinforced rubber roofing, the rubber has a fabric in the middle and is rated for 100mph wind.

It has lasted very well even getting scrapped by tree branches over the years, and living out doors for many years in the rain and the snow. No leaks. Can be painted with rubber paint and the reinforcement gives it the look of canvas.

When I went to the commercial roofing company and told the guy what was restoring, showed him a picture, he went and found a piece of scrap twice the size of what I need. When I got out my check book he said no you can have it.

Cheers Phil

[Robert Bergeron]

Thank you very much Phil , that is a great idea ! In my case the roof is made of two aluminium sheets . The challenge is to prevent water from seeping in by the dozens of holes created by sheet metal screws , bolts and lag screws .

[Robert Bergeron]

There are 14 hooks total , 7 each side attached to the aluminium roof . They serve as anchors to hold up the penthouse tent . Logicaly that tent goes on the left ( passenger ) side where the map table hooks up on the outside wall . Why they would have hooks on the generator compartment side is beyound me , mere restorer .

[Robert Bergeron]

Hooks on the cypher clerk side of the box . A lot of hooks . Originaly they were set with flimsy rivets and all of mine were gone. I went with 1/4” bolts after enlarging slightly the original holes along the roof .I will be using an awning instead of a tent .

[Robert Bergeron]

Primed the underside of the new floor today . Nice & tidy .

[Robert Bergeron]

Reunited at last .Now that the box has a good roof and good floor it was time to reunite it with the truck . It will be easier to move it in and out of the garage and take less room than when they were seperated .
