Modified Conventional Pattern Trucks

[Hanno Spoelstra]

To some it may seem a moot point, but since this is a very anorak subject anyway I would like to differentiate between the various “patterns” built during WW2, instead of throwing all non-CMP trucks on the “MCP heap”. Although the line between the various patterns is not always clear, I have tried to make a listing, mainly based on Vanderveen and Gregg:

1. Standard, Conventional or Commercial: used in great numbers by military users. Military modifications ranged from none, to matt paint plus black-out lighting, to off-road tyres and military cargo bodies. Canadian forces at home used mainly US type commercial trucks.


2. Modified Conventional Pattern (MCP): standard types with modifications to meet military requirements, comprising cars, utilities, 15-cwt, 2-ton and 3-ton trucks. Shipped out in large numbers, notably for use in the North African campaigns. Fitted with uprated chassis, springs, WD split rims (13, 16 and 20”), single rear tyres, RHD (for overseas use), military bumper and push bar, black out lighting system, WD towing hook, matt paint, etc.
   Over 300,000 MCP trucks were produced in Canada by Chrysler, Ford and General Motors.


3. Local Pattern, later: Australian Pattern: referred to as such to distinguish them from overseas military pattern vehicles which were also used. Most Australian Pattern vehicles produced early in the war were militarised commercial types (4x2, 4x4, 6x6). All were adaptations or modifications of commercial-type vehicles, mostly of North American origin and assembled in Australia with locally produced cabs and bodywork. Many were fitted with oversize tyres (incl. 18”), single rear.
   This class also included tracked carriers, armoured cars, tanks and trailers.


4. Department of National Defence (DND) Pattern, later: Canadian Military Pattern (CMP): a class of vehicles, devised and developed in Canada by Ford and GM, guided to a large extent by developments in Britain and fitting within British chassis (load) classifications. They combined British War Office design features (forward control, large single tyres, etc.) with American engineering (engines, transmissions, axles, etc.) and mass-production techniques. Thus main standard commercial components were used (engines, gearboxes), driven front axles patterned on the American Marmon-Herrington design, using standard type differentials. High degree of standardisation throughout the CMP range of vehicles.
   In Australia CMPs were officially known as CWO (Canadian War Office), but popularly known as “Blitz” trucks.

To be updated later, meanwhile your input is appreciated.

Thanks,
